Anti-optical camouflage net matches the spectral reflective properties in the ultraviolet, visible and near-infrared wavelengths with the background, thus possessing anti-optical reconnaissance capability. It can be widely used in the optical camouflage of equipments and facilities. The product has passed ISO9001:2015 quality management system certification.
Structure: Skeleton mesh composite cut flower decorative sheet structure
Camouflage Type: Mainly includes woodland type camouflage and desert type camouflage, also can be customized
Application Scenarios: Mainly used for military equipment, weapons, military facilities and other military targets in the visible light, part of the ultraviolet, part of the near-infrared wavelength optical camouflage, stealth, but also can be used as civil decoration, sunshade and other camouflage. Performance advantage: Adopting high-strength polyester reinforcing silk as the skeleton, cut flower process molding, high-strength wear resistant, lightweight and portable, cost-effective
Technical Parameters
◆ Weight
≤250g/m²
◆ Physical & Mechanical Properties
Rupture strength: Warp ≥ 500N, Weft ≥ 500N
Tear strength: Warp≥ 50N, Weft≥ 50N
◆ Flame retardant properties
Re-ignition time no more than 10s
◆ Camouflage performance
1) Protection band: 380nm~1200nm
2) Gloss: each camouflage color 60 ° gloss is not greater than 5 gloss units
3) Visibility: each camouflage unit obscures no more than 50 percent of the target's visibility
4) Light reflection properties
①Similar image characteristics to the corresponding background on visible and near-infrared images, with a comb ined luminance contrast of no more than 0.2
② In the wavelength interval of not more than 10nm at each detection wavelength, and its corresponding background dominant color 03. Camouflage Product Series between the spectral reflectance contrast in the visible wavelength band is not greater than 0.1, and not more than 0.2 in the near-infrared wavelength band
◆ Environmental adaptation
The color difference before and after 500h artificial climate aging is less than 3 levels
◆ Life span
1) A storage lifespan is not less than 10 years
2) A cumulative field lifespan is not less than 5 years
